Specifications | SAE_UE_MS_CSBWE |
| Range of product | ARGUS |
| Country of Origin (Estimated) | China (Other) |
| Warranty | 12 months |
| CO/CQ | Yes (if) |
| Product or component type | Occupancy sensor |
| IP degree of protection | IP20 |
| Load type | Halogen lamp <= 1000 VA
Energy saving lamp <= 80 VA
Incandescent lamp <= 2000 W
Low voltage halogen lamp <= 1000 VA
Fluorescent lamp 100 µF <= 900 VA |
| Rated voltage | 230 V +/- 10 % AC 50/60 Hz |
| Detection angle | 360° (Góc quay Sensor quét được 360° ) |
| Presence detection area | PIR: 360°, 7 x 7 m |
| Device mounting | Surface (gắn âm) |
| Mounting support | Ceiling (Gắn tường) |
| Mounting height | 2…3 m (Gắn ở độ cao tầm 2-3 mét) |
| Ambient air temperature for operation | 0…45 °C |
| Standards | EN 60669-1
EN 60669-2-1 |
| Diameter | 120 mm |
| Depth | 41 mm |
