Cầu Dao Bảo Vệ Động Cơ 3P 0.4-0.63A Nhấn Mở


CB Bảo Vệ Motor 3P 0.4-0.63A

  • Mã sản phẩm: GV2ME04
Giá bán: 913.990 ₫ (bao gồm VAT)
Giá gốc: 1.589.500 ₫ (bao gồm VAT)
Tình trạng tồn kho: Còn hàng

Motor circuit breaker, TeSys Deca, 3P, 0.4 to 0.63A, thermal magnetic, screw clamp terminals, button control.

Specifications
RangeTeSys GV2
TeSys Deca
Country of Origin (Estimated)Thailand (Other)
Warranty12 months
CO/CQYes (if)
Product name & Device short nameGV2ME
Device applicationMotor protection
Trip unit technologyThermal-magnetic
Poles description3P
Motor power kW0.12 kW at 400/415 V AC 50/60 Hz
Breaking capacity00 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
100 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service short-circuit breaking capacity100 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
100 % at 440 V AC 50/60 Hz conforming to IEC 60947-2
Control typePush-button
[In] rated current0.63 A
Thermal protection adjustment range0.40…0.63  A conforming to IEC 60947-4-1
Magnetic tripping current8A
[Ue] rated operational voltage690 V AC 50/60 Hz conforming to IEC 60947-2
Dimensions (mm)
(WxHxD)
45x89x78.5 mm
Net weight (Kg)0.26 kg
