Cầu Dao Bảo Vệ Động Cơ 3P 20-25A Nhấn Mở


CB Bảo Vệ Motor 3P 20-25A

  • Mã sản phẩm: GV2ME22
Giá bán: 1.075.250 ₫ (bao gồm VAT)
Giá gốc: 1.870.000 ₫ (bao gồm VAT)
Tình trạng tồn kho: Còn hàng

Motor circuit breaker, TeSys Deca, 3P, 20 to 25A, thermal magnetic, screw clamp terminals, button control

Specifications
RangeTeSys GV2
TeSys Deca
Country of Origin (Estimated)Thailand (Other)
Warranty12 months
CO/CQYes (if)
Product name & Device short nameGV2ME
Device applicationMotor protection
Trip unit technologyThermal-magnetic
Poles description3P
Motor power kW11 kW at 400/415 V AC 50/60 Hz
Breaking capacity15 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
6 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service short-circuit breaking capacity40 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
50 % at 440 V AC 50/60 Hz conforming to IEC 60947-2
Control typePush-button
[In] rated current25A
Thermal protection adjustment range20…25 A conforming to IEC 60947-4-1
Magnetic tripping current327 A
[Ue] rated operational voltage690 V AC 50/60 Hz conforming to IEC 60947-2
Dimensions (mm)
(WxHxD)
45x89x78.5 mm
Net weight (Kg)0.26 kg
