Safety switches XCSM, metal, roller plunger, 2NC + 1NO, cable 5 m.
Specifications | XCSM3902L5 |
| Range of product | Telemecanique Safety switches XCS |
| Product or component type | Safety limit switch |
| Device short name | XCSM |
| Design | Miniature |
| Material | Metal |
| Head type | Plunger head |
| Protection technology | Plastic protective cover, secured by 5-lobe socket head safety screw |
| Type of approach | Lateral approach |
| Type of operator | Roller plunger |
| Contacts type and composition | 1 NC + 1 NC + 1 NO |
| Contact operation | Snap action |
| Electrical Connection | Pre-cabled |
| Cable length | 16.4 ft (5 m) |
| Cable composition | 7 x 0.5 mm² |
| Switch actuation | By 30° cam |
| Fixing Mode | By the body |
| Number of poles | 3 |
| Positive opening | With NC contact |
| Mechanical durability | 10000000 cycles |
| Body material | Zamak |
| Head material | Zamak |
| Depth | 16 mm |
| Height | 70 mm |
| Width | 30 mm |
| Net Weight | 0.17 kg |
