A9MEM3110 - Đồng Hồ Đo Điện Năng Trực Tiếp Gắn Din-rail 63A


Đồng Hồ Schneider Đo Điện Năng Trực Tiếp 63A

  • Mã sản phẩm: A9MEM3110
Giá bán: 3.675.980 ₫ (bao gồm VAT)
Giá gốc: 8.354.500 ₫ (bao gồm VAT)
Tình trạng tồn kho: Tạm Hết

iEM3110 Energy Meter - 63 A - 1 pulse O - MID, Maximum value measured 99999999.9 kWh.

Specifications
Range of productActi9 Iem3000
Country of Origin (Estimated)China
Warranty12 months
CO/CQYes (if)
Product name & Device short nameiEM3110
Product or component typeEnergy meter
Device applicationPartial meter
Sub billing
Poles description3P
1P + N
3P + N
Type of measurementActive energy
Accuracy classClass 1 active energy conforming to IEC 62053-21
Class 1 active energy conforming to IEC 61557-12
Class B active energy conforming to EN 50470-3
Input typeDirect input
[In] rated current63 A
Rated voltage100…277 V
173…480 V
Technology typeElectronic
Display typeLCD display
Measurement current0…63 A
Maximum value measured99999999.9 kWh
Number of inputs0
Number of outputs1 pulse
Mounting supportDIN rail
Dimensions (mm)
(H x W x D)
95x90x69 mm
Net weight429 GRM
