Khởi động từ Giga 3P 185A cuộn coil 200-500VAC/DC


Contactor Giga 3P 185A Coil 200-500VAC/DC

  • Mã sản phẩm: LC1G185LSEA
Giá bán: 11.436.920 ₫ (bao gồm VAT)
Giá gốc: 19.890.200 ₫ (bao gồm VAT)
Tình trạng tồn kho: Hết hàng

High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 185A, advanced version, 200…500V wide band AC/DC coil

Specifications
RangeTeSys Giga
Country of Origin (Estimated)China (Other)
Warranty12 months
CO/CQYes (if)
Product name & Device short nameLC1G
Device applicationPower switching
Motor control
Poles description3P
[Ie] rated operational current305 A (at <40 °C) at <= 1000 V AC-1
185 A (at <60 °C) at <= 440 V AC-3
[Ue] rated operational voltage<= 1000 V AC 50/60 Hz
<= 460 V DC
[Uc] control circuit voltage200...500 V AC 50/60 Hz
200...500 V DC
StandardsEN/IEC 60947-4-1
EN/IEC 60947-5-1
UL 60947-4-1
CSA C22.2 No 60947-4-1
JIS C8201-4-1
JIS C8201-5-1
Pole contact composition3 NO
Auxiliary contact composition1 NO + 1 NC
Connection pitch35 mm
Dimensions (mm)
(HxWxD)
255x108x193 mm
Net weight (Kg)4.1 kg
Motor power kW90 kW at 400 V AC 50/60 Hz (AC-3e)
90 kW at 415 V AC 50/60 Hz (AC-3e)
110 kW at 440 V AC 50/60 Hz (AC-3e)

Danh sách tài liệu của sản phẩm

STTTên tài liệuTài về
1LC1G185LSEA_Datasheet.pdf
2Catalogue Contactor LC1G Schneider
3Bảng giá Price list Contactor LC1G
