Bộ Ngắt Mạch Tự Động CVS100B 3P 40A 25KA TMD


MCCB 3P 40A 25KA CVS100B TMD

  • Mã sản phẩm: LV510303
Giá bán: 1.842.940 ₫ (bao gồm VAT)
Giá gốc: 3.613.500 ₫ (bao gồm VAT)
Tình trạng tồn kho: Còn hàng

Circuit breaker, EasyPact CVS100B, 25kA at 415VAC, 40A, TM-D trip unit, 3P3d

Specifications LV510303
RangeEasyPact
Country of Origin (Estimated)India
Warranty12 months
CO/CQYes (if)
Product name & Device short nameEasypact CVS100B
Device applicationDistribution
Poles description3P /4P
Protected poles description3P 3d /4P 3d
[In] rated current32 A at 40 °C
Network typeAC
[Ue] rated operational voltage440 V AC 50/60 Hz conforming to IEC 60947-2
Suitability for isolationYes conforming to IEC 60947-2
Trip unit nameTM-D
Trip unit technologyThermal-magnetic
Trip unit rating32 A
Thermal protection adjustment range22.4…32 A
Long time pick-up adjustment range0.7...1 x In
[Ui] rated insulation voltage690 V AC 50/60 Hz conforming to IEC 60947-2
Connection pitch35 mm
Breaking capacity [Icu]25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service breaking capacity25 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
Mechanical durability30,000 cycles
Electrical durability12000 cycles 415V In conforming to IEC 60947-2
Protection typeShort-circuit protection (magnetic)
Overload protection (thermal)
Dimensions (mm)
(W x H x D)
3P/105x161x86mm
4P/140x161x86mm
Net weight (Kg)3P/1.8Kg
4P/2.2Kg
Front-panel Cutouts
For toggle (X*Y)
29x76mm
Front-panel Cutouts
For toggle with access to trip unit
3P/108x180mm
4P/143x108mm
