Voltage monitoring relay 2C/O, B-C=3-600VRMS, 220-240VAC (CM-ESS.2S)
Specifications | 1SVR730831R1400 |
| Extended Product Type | CM-ESS.2S |
| Country of Origin (Estimated) | Germany (Other) |
| Warranty | 12 months |
| CO/CQ | Yes (if) |
| Product or component type | Voltage Monitoring Relay |
| Catalog Description | CM-ESS.2S Voltage monitoring relay 2c/o, B-C=3-600VRMS, 220-240VAC |
| Function | Over- or undervoltage monitoring |
| Measuring Range | 3 ... 30 V
6 ... 60 V
30 ... 300 V
60 ... 600 V |
| Time Range | 0 s or 0.1 ... 30 s tripping delay (ON) |
| Rated Control Supply Voltage (Us) | 220 ... 240 V AC |
| Output | 2 c/o (SPDT) contacts |
| Terminal Type | Screw Terminals |
| Rated Operational Current AC-12 (Ie) | (230 V) 4 A |
| Rated Operational Current DC-12 (Ie) | (24 V) 4 A |
| Electrical Durability | AC-12 100000 cycle |
| Mechanical Durability | 30000000 cycle |
| Tightening Torque | 0.6 ... 0.8 N·m |
| Mounting on DIN Rail | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 |
| Standards | CAN/CSA C22.2 No.14
IEC/EN 63000
IEC/EN 60255-27
IEC/EN 61000-6-2
IEC/EN 61000-6-3
UL 508 |
| Dimensions (WxHxD) | 22.5 x 85.6 x 103.7 mm |
| Net weight | 0.181 Kg |
