Rờ Le Nhiệt TeSys Giga 28-115A, Class 5E-30E


Rờ Le Nhiệt TeSys Giga 28-115A, Class 5E-30E

  • Mã sản phẩm: LR9G115
Giá bán: 5.402.210 ₫ (bao gồm VAT)
Giá gốc: 9.395.100 ₫ (bao gồm VAT)
Tình trạng tồn kho: Còn hàng

Electronic Thermal Overload Relay,TeSys Giga,28 - 115 A,class 5E-30E,push-in control connection.

Specifications

LR9G115

Country of Origin (Estimated)China
Warranty12 months
CO/CQYes (If need)
Product nameTeSys LRG
Product or component typeElectronic thermal overload relay
Device short nameLR9G
Relay applicationMotor protection
Network typeAC
Thermal overload classClass 5E...30E conforming to IEC 60947-4-1
Thermal protection adjustment range28…115 A
Tripping threshold1.125 +/- 0.07 In conforming to IEC 60947-4-1
Local signallingLED
Trip indicator
Contacts type and composition1 NO + 1 NC
[Ith] conventional free air thermal current5A
[Uc] control circuit voltage24...500 V AC 50/60 Hz
24...250 V DC
[Ue] rated operational voltage1000 V AC 50/60 Hz
ResetAutomatic reset
Manual
Mounting supportDirect on contactor
Plate
StandardsEN/IEC 60947-4-1
EN/IEC 60947-5-1
UL 60947-4-1
CSA C22.2 No 60947-4-1
JIS C8201-4-1
JIS C8201-5-1
IEC 60335-1:Clause 30.2
IEC 60335-2-40:Annex JJ
UL 60335-2-40:Annex JJ
UL 60335-1
Dimensions (mm)
(HxWxD)
107x105x126 mm
Net weight (Kg)0.9 kg
